V800TP-15-S1V4P2

Core Positioning

A dedicated turn-mill compound system featuring a 15-inch large screen and advanced 4-axis control. Designed for integrated turning, milling, and drilling of complex parts, it focuses on high performance and multi-axis linkage capability.

Hardware and Interface

The 15-inch HD touchscreen provides a wider view and more precise operation. With a fanless industrial-grade design and enhanced oil and dust resistance, it is suitable for heavy-cutting and dusty environments in turn-mill compound machining.

Control Capability

Upgraded 4-axis control (S1V4) supports X/Z/C/Y axis linkage, or dual spindles plus dual turrets, meeting the requirements of compound turning, milling, drilling, and tapping. Advanced dual-channel functions support synchronized high-speed spindle positioning and high-speed feed interpolation.

Communication and Expansion

With full bus coverage including EtherCAT, MII, MIII, and RTEX, it is compatible with high-end servos and linear motors. It offers powerful secondary development capabilities and supports complex applications such as turn-mill compound machines, Swiss-type lathes, double-head lathes, and integrated control of lathes plus robotic arms.

Typical Applications

Suitable for turn-mill compound machining centers, Swiss-type CNC lathes, double-head precision lathes, and one-stop machining of complex irregular parts such as medical devices and small aerospace parts. It is ideal for Industry 4.0 intelligent production lines.
