V800MB-10-S1V5P2

Core Positioning

A dedicated 10.4-inch milling machine system for vertical installation, designed to meet the compact installation needs of vertical milling machines and slant-bed machining centers while balancing 5-axis performance and space utilization.

Hardware and Interface

The 10.4-inch vertical touchscreen is suitable for vertical machine tool operation panel layouts. With a fanless, high-protection design for oil and dust resistance, it features a compact structure that saves installation space. Built with industrial-grade quality, it is suitable for milling conditions involving heavy dust and heavy cutting.

Control Capability

With the same-specification 5-axis control (S1V5), it supports X/Y/Z/A/B axis linkage plus spindle control, meeting the milling requirements of complex cavities and curved surfaces on vertical milling machines. It also supports basic dual-channel functions, enabling high-speed spindle positioning and synchronized high-speed feed interpolation.

Communication and Expansion

Fully compatible with EtherCAT, MII, MIII, RTEX, and other buses, it adapts to mainstream servo and spindle drives on the market. Open secondary development interfaces support advanced scenarios such as linkage between milling machines and simple robotic arms, as well as multi-station automated machining.

Typical Applications

Suitable for vertical CNC milling machines, small machining centers, and precision engraving and milling machines. It is ideal for vertical milling applications with limited height and a focus on convenient operation.
