V800TB-10-S1V3P2

Core Positioning

A dedicated 10.4-inch lathe system for vertical installation, designed to meet the compact installation needs of vertical lathes and slant-bed lathes while balancing performance and space utilization.

Hardware and Interface

The 10.4-inch vertical touchscreen is suitable for vertical machine tool operation panel layouts. With a fanless, high-protection design for oil and dust resistance, it features a compact structure that saves installation space.

Control Capability

With the same-specification 3-axis control (S1V3), it supports X/Z axis linkage plus spindle control, adapting to feed and spindle control requirements of vertical lathes and slant-bed lathes. It also supports basic dual-channel functions, enabling independent control of the spindle and feed axes.

Communication and Expansion

Fully compatible with EtherCAT, MII, MIII, RTEX, and other buses, it adapts to mainstream servo systems on the market. Open secondary development interfaces support advanced scenarios such as lathe linkage with simple robotic arms and basic control for Swiss-type lathes.

Typical Applications

Suitable for vertical CNC lathes, slant-bed precision lathes, and small turning centers. It is ideal for vertical machining scenarios with limited height and a focus on convenient operation.
